Prototype printing
Print the model that
answers your next question.
An early prototype can be deliberately selective. A rounded shell can represent a proposed grip without containing controls. A plain block can represent a product’s maximum outside dimensions without reproducing every groove. State what needs to be represented accurately, and what can remain unfinished.
Our Leicester workshop offers FDM, large-format FDM and resin printing within its 20+ printer fleet. Available processes give you options; the useful starting point is the decision the model needs to support.
Prototype planning guide
Choose the purpose
of your first prototype.
Write one sentence before choosing a material: “This prototype will help me decide…” Finish it with a specific question. Early form models and later working prototypes can serve different purposes. Formlabs’ guide to prototyping tools explains that distinction; the decision tree below applies it to a print brief.
1. Is the question about appearance?
Keep the silhouette, visible proportions and surfaces you want to judge. Identify the viewing angle and whether colour or finish is part of the question. Detail hidden inside the part may be unnecessary for this stage.
Example question: “Which of these two outer forms should we develop?”
It would not establish: the final material’s strength, electronic performance or a person’s comfort in use.
2. Is the question about overall size or occupied space?
Preserve the dimensions that define the occupied space, including protrusions, feet and any attached item relevant to that space. Use the real scale and units. Decide whether the question is simply an outer-envelope check or whether a shaped interface must also be represented.
Example question: “Is this the amount of space we should reserve in the carton?”
It would not establish: cushioning, protection in transit, product mass or centre of gravity. See the packaging study for the limits of a plain volume block.
3. Is the question about assembly?
Keep the mating surfaces, alignment references and access needed for the particular operation. Supply the other component or its relevant dimensions, not only an isolated part file. State whether the pieces need to slide, locate, close or be removable.
Example question: “Can the face plate be positioned and removed in the intended sequence?”
It would not establish: a guaranteed fit from a nominal dimension alone. Clearances, material and process need agreement, followed by a suitable physical assessment. An empty shell illustration is not a validated enclosure drawing.
4. Is the question about performance?
Define the load, movement, temperature or environment, the intended material and a meaningful acceptance criterion. A visually convincing model is not enough evidence for a working part. A performance prototype needs a representative design and an appropriate assessment for that purpose. Formlabs’ product-development guidance separates focused models from broader engineering validation.
Example question: “What must this part withstand, and how will that be established?”
It would not establish: safe or reliable use without that assessment. No performance result is claimed for the fictional studies.
More than one question?
Put the questions in order. For a controller, an outer-form comparison could come before a detailed internal arrangement. For packaging, the space reservation could come before a representative packaged-product assessment. Keep a short record of what each version is meant to teach you.
Compare one change at a time
When comparing two grip proposals, keep the intended overall length and relevant reference features consistent. If the review involves handling, differences in mass, texture and finish could also influence the impression. The orange and green colours in our illustrations identify alternatives; they are not a controlled physical comparison.
Send a brief that makes the purpose clear
- The question this prototype should help answer.
- The model or sketch, its units and the required overall dimensions.
- The features that must be preserved and the details that may be simplified.
- The number of samples of each option.
- Any mating part, viewing surface, use condition or deadline relevant to the question.
What should your first print tell you?
Bring the question, the model and the dimensions that matter. Explore your next step with 3D Printing Leicester.
